4.2.1 Click & Plug - connection coupling
The Click & Plug connection coupling supplied with the Connexx system is to be used for
connecting the system quickly and reliably with the container outlet fitting.
The coupling only fits on the extraction nozzles of containers with integrated
suction lance from Ecolab.
Fig. 3: Click & Plug coupling
1 Connection for ID19 hose
2 Handle bar
3 Coupling shoe
CAUTION!
The coupling may only be connected to Ecolab containers with an integrated
suction lance whose extraction nozzles are identical in colour and size. Use for
other colour coding or other Connexx systems is not permitted and can have
serious consequences for health, safety and function. In addition, it is not
permitted to remove the extraction nozzles or open the containers.
Functional description
16Rev. 1-06.2018
