FLEX FUEL SENSOR
A FlexFuel sensor measures the ethanol content of the fuel as it passes through the fuel system.
Information about ethanol content can be utilized by the ECUMASTER EMU to adjust the fuel
dose, ignition advance, or boost pressure. The EMU supports GM/Continental frequency sensors.
The FlexFuel sensor should be connected to the CAM#2 input or to VSS input if the CAM#2 input
is used for a camshaft position sensor. To activate the FlexFuel sensor, the Enable FlexFuel
parameter should be checked and Table switch mode should be set to FlexFuel blend in options
menu Other/Tables switch.
Parameters
PARAMETER FUNCTION
Enable FlexFuel Activates FlexFuel sensor support
Sensor input Defines EMU input used for FlexFuel sensor (CAM#2 or VSS)
Maximum TPS to read
sensor
Maximum throttle position under which the ethanol content will be
read from the sensor (clamps the ethanol content signal at high
throttle inputs)
Blend VE tables Activate blending between VE #1 and VE #2 tables
Blend IGN tables Activate blending between IGN #1 and IGN #2 tables
Blend AFR tables Activate blending between AFR #1 and AFR #2 tables
Blend Boost tables
Activate blending between Boost DC Ref #1 and Boost DC Ref #2,
and Boost target #1 and Boost target #2 tables
Blend fuel when
cranking tables
Activate blending between Cranking fuel #1 and Cranking fuel #2
tables
Blend ASE tables
Activate blending between ASE #1 i ASE #2 tables (afterstart
enrichment)
Blend warmup tables Activate blending between Warmup tbl. #1 and Warmup tbl. #2
Page 104
EMU
B6
+12V
CAM#2 or VSS Input
FF
Sensor
