Param. output
Parametric output strategy can be used to perform specific functions like alternator control, electric
pumps, electric blow off valve, variable intake manifold length etc.
Parametric Output 1 has 3 conditions that control the state of the output, the other parametric
outputs have only 2 conditions. These conditions can be combined with logical operators OR /
AND.
PARAMETER DESCRIPTION
Output Device output to control with the parametric output strategy
Invert output Reversal of output state
Variable #X type
The first condition variable: RPM, MAP, TPS, IAT, CTL, VSS, analog
input voltage Analog In#, Oil pressure, Oil temperature, Fuel pressure,
battery voltage
Variable #X operator
Mathematical operator of the condition to change the state of the
output: GREATER THAN , LOWER THAN , EQUAL OR GREATER
THAN, LOWER THAN OR EQUAL
Variable #X value
The value on which the output depends (unit depends on the variable
type)
Variable #X hysteresis Hysteresis limit value at which it will return to its original state
Logical operator 1 Option adds next condition with logical operator "OR" "AND"
Enable cycling Turns cyclic operation
Cycling on time The time for which the output will be active
Cycling off time The time for which the output is not active
Cycle once Option turn of cycling after one cycle
