EGO feedback
EGO feedback configuration window is used to set up EGO closed loop correction operation
parameters. Both wideband and narrowband sensors can be used for correction. In case of
narrowband sensor, it's only possible control mixture content around stoichiometric (NBO Ref
Target). Use of wideband sensor allows controlling mixture to achieve values set in AFR table.
PARAMETER DESCRIPTION
Enable EGO
feedback
Enables EGO closed loop correction
Rich limit Fuel mixture enrichment limit
Lean limit Fuel mixture leaning limit
NBO change step
Used only with narrowband sensor. Defines fuel dose correction step size in
percent
NBO change rate
Used only with narrowband sensor. Defines correction calculation interval in
engine revolutions
NBO ref target Reference voltage to be held for narrowband sensor correction
Warmup time Defines how long the system is inactive after engine start
TPS limit Minimal TPS value for EGO feedback to be active
Min CLT Minimal engine coolant temperature for EGO feedback to be active
Min RPM Minimal engine RPM for EGO feedback to be active
Max RPM Maximum engine RPM for EGO feedback to be active
Min MAP Minimal Manifold Air Pressure for EGO feedback to be active
Max MAP Maximum Manifold Air Pressure for EGO feedback to be active
Fuel Cut delay Time in ms for EGO feedback to be reactivated after fuel cut
EGO kP Proportional gain of EGO correction PID controller
EGO kI Integral gain of EGO correction PID controller
EGO Integral Limit Limit to prevent PID controller integral windup
