Extra sensors
Extra sensors configuration window allows you to select which inputs additional sensors are
connected to. Example sensors that have special functions in EMU software are Oil pressure, Oil
temperature, Fuel pressure and Fuel level sensors.
PARAMETER DESCRIPTION
Oil pressure input
Analog input used to read oil pressure sensor value. Sensor
calibration can be found in Sensors setup / Oil press. cal. table
Oil temperature sensor
input
Analog input used to read oil temperature sensor value. Sensor
calibration can be found in Sensors setup / Oil temp. cal. table
Fuel pressure sensor
input
Analog input used to read fuel pressure sensor value. Sensor
calibration can be found in Sensors setup / Fuel press. cal. table
Fuel level sensor input
Analog input used to read fuel level sensor value. Sensor calibration
can be found in Sensors setup / Fuel level cal. table
Analog Inputs
EMU device has 4 analog inputs, which can be used as inputs activating functions of the device,
such as, e.g., launch control, or to log in signals from additional sensors. There is a possibility to
configure sensors, so that voltage from the sensor is presented as physical value, e.g., pressure
expressed in bars. To configure sensors connected to analogue inputs you have to use parameters
Analog Inputs.
PARAMETER DESCRIPTION
AIN#X unit Unit displayed after calculated value from analog input X
AIN#X ratio Ratio of displayed value to input voltage (slope of linear function)
AIN#X offset Offset added to value multiplied by ratio (intercept of linear function)
AIN#X min. Minimum allowed value
AIN#X max. Maximum allowed value
Displayed value [UNIT] = Input voltage * RATIO + OFFSET
