ECU Master EMU - Axis Bins Wizard; RPM Bins Wizard

X axis bins wizard
This wizard is used for automatic generation of set points
for the load axis (X).
PARAMETER DESCRIPTION
Load min value Minimal value for axis X
Load max value Maximal value for axis X
Interpolation type
The way of dividing set points on axis X between the minimal and maximal
value. We have 3 options to choose from:
Linear interpolation – linear interpolation between values
Exponential interpolation 1 – exponential interpolation, version 1
Exponential interpolation 2 – exponential interpolation, version 2
RPM bins wizard
Wizard of RPM values for scale Y acts identically as
wizard for axis X.
Page 25
