CONFIGURATION OF IGNITION PARAMETERS
Configuration of ignition parameters is crucial from the point of view of the correct engine work and
should be performed with the utmost care.
Primary trigger
Primary trigger options are responsible for configuring the main sensor directing ignition system
and base ignition advance. The signal source (sensor) can be located on the crankshaft as well as
on the camshaft. After each change of parameters, the ignition angle should be checked with a
timing light.
ATTENTION !
Proper configuration of the ignition system is essential for safe operation of the
engine!
ATTENTION !
After each modification to the ignition system parameters it is necessary to
check ignition angle advance using a timing light
Depending on the type of the sensor, the scheme of connections looks as follows:
Page 63
EMU
B7
B23
Hall
Hall's / Optical sensor connection
B18
+5V
GND
Out
