Honda CLT dash output
Honda CLT dash function is used to generate coolant temperature signal from EMU to the
electronic indicator on the dashboard of the Honda S2000.
PARAMETER DESCRIPTION
Enable Enable signal generation
Output Output to which indicator is connected
CLT Freq. output
The Clt freq. output function is used to generate a signal with a frequency dependent on the
coolant temperature. Frequency for a given temperature is defined on the Clt freq. Output table.
This function is used to provide a signal that can be read by some models of instrument clusters.
PARAMETER DESCRIPTION
Output Output to which indicator is connected
PWM#1 CLT scale
PWM#1 CLT scale table scales the value of duty for PWM #1 from a table dependent on coolant
temperature. This feature allows you to generate a signal for coolant temperature indicator or
a water pump controlled by a PWM signal. This table is used by PWM Output #1 function.
Page 93
