Status bar
Status bar shows the most important parameters of EMU device to allow easy trace of them.
DESCRIPTION OF STATUS BAR
Connection status
DISCONNECTED - there is no communication with EMU device
CONNECTED - communication with EMU device established
Ignition status
Information about synchronization of ignition system
NO SYNC – no synchronization
SYNCHRONISING – trying to synchronize
SYNCHRONISED – ignition system synchronized
STATE
Current state of the EMU device
INACTIVE - there are no calculations connected to fuelling and
ignition system
CRANKING - in this state fuel dose is taken directly from Cranking
fuel table, and ignition angle is defined by Cranking ignition angle
parameter
AFTERSTART - the engine is running, Afterstart enrichment is present
RUNNING - the engine is running normally
TBL SET Information about current tables set
CAN BUS
Current state of CAN BUS module
BUS OK - CAN BUS module works correctly
MODULE DISCONNECTED - CAN BUS module is not connected to
extension port
BUS ERROR - CAN BUS error (inappropriate speed, wrong
connection, termination problems)
CEL Information about "check engine light"
FW VER Firmware version of connected EMU device
LC Launch control strategy active
FC Fuel cut
SC Spark cut
ALS ALS strategy active
KS Knocking occurs
RAL Rolling antilag strategy active
IDL Idle control strategy active
PO1-PO4 Parametric outputs state
