Chapter 19
| Spanning Tree Commands
– 521 –
Command Mode
Privileged Exec
Command Usage
◆ Use the show spanning-tree command with no parameters to display the
spanning tree configuration for the switch for the Common Spanning Tree
(CST) and for every interface in the tree.
◆ Use the show spanning-tree interface command to display the spanning tree
configuration for an interface within the Common Spanning Tree (CST).
◆ Use the show spanning-tree mst command to display the spanning tree
configuration for all instances within the Multiple Spanning Tree (MST),
including global settings and settings for active interfaces.
◆ Use the show spanning-tree mst instance-id command to display the
spanning tree configuration for an instance within the Multiple Spanning Tree
(MST), including global settings and settings for all interfaces.
Example
Console#show spanning-tree
Spanning Tree Mode : MSTP
Spanning Tree Enabled/Disabled : Enabled
Instance : 0
VLANs Configured : 1-4094
Priority : 32768
Bridge Hello Time (sec.) : 2
Bridge Max. Age (sec.) : 20
Bridge Forward Delay (sec.) : 15
Root Hello Time (sec.) : 2
Root Max. Age (sec.) : 20
Root Forward Delay (sec.) : 15
Max. Hops : 20
Remaining Hops : 20
Designated Root : 32768.0.00E00C0000FD
Current Root Port : 0
Current Root Cost : 0
Number of Topology Changes : 6
Last Topology Change Time (sec.): 8
Transmission Limit : 3
Path Cost Method : Long
Flooding Behavior : To VLAN
---------------------------------------------------------------
Eth 1/ 1 information
---------------------------------------------------------------
Admin Status : Enabled
Role : Designate
State : Forwarding
External Admin Path Cost : 0
Internal Admin Path Cost : 0
External Oper Path Cost : 100000
Internal Oper Path Cost : 100000
Priority : 128
Designated Cost : 0
Designated Port : 128.1
Designated Root : 32768.0.00E00C0000FD
Designated Bridge : 32768.0.00E00C0000FD
Forward Transitions : 6
