4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL 0004842_REV_N
5.8 Part Numbers for Major Tow Vehicle Components
The major tow vehicle components and their part numbers are listed below:
DESCRIPTION, PART NUMBER
100/400
300/600
300/900
4200-SP
COMPASS MODULE, 0008518
X
X
X
X
KONTRON CPU ASSY, 0012666
X
X
X
X
ASSY AMP, BD 0006125
X
X
X
X
T/R BD, 0006173
X
-
T/R BD, 0007433
X
-
T/R BD, 0008514
X
-
SSAC BD, 0006163
X
DDC BD, 0007432
X
X
-
SONAR/IDE BD, 0006102
X
X
X
-
DSL MODEM, 0006104
X
X
X
-
POWER DIST BD, 0006134
X
X
X
-
SHEAR PIN 5/16”, 0006301
X
X
X
-
100/400 RX XDUCER, 0003029
X
100/400 TX XDUCER, 0003030
X
300/600 RX XDUCER, 0008228
X
300/600 TX XDUCER, 0008229
X
300/900 TX XDUCER, 0007462
X
300/900 RX XDUCER, 0007461
X
100/400 RX/TX SP XDUCER 0003031
X
300/600 RX/TX SP XDUVER 0008770
X
300/900 RX/TX SP XDUCER 008772
X
TAIL FIN, 350-0000742-0300 (0008146)
X
X
X
Table 5-5: Part Numbers for Major Tow Vehicle Components
5.9 Tow Vehicle Outline Drawings
Outline drawings of the tow vehicle and the tow vehicle tail fins are found in sub-section C.2 TOW
VEHICLE OUTLINE DRAWINGS
