4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL 0004842_REV_N
5.3 Calibrating the Compass
The compass is calibrated at the EdgeTech manufacturing facility and should not require additional
calibration. Please contact CUSTOMER
SERVICE for support if the compass needs to be recalibrated.
5.4 Topside Processor Troubleshooting Guides
Should some operational or performance problems occur with the 4200 Series High Definition Dual-
frequency Side Scan Sonar System, it may be possible to correct them using the troubleshooting guides in
the following pages. For the 4200 Rack Mount, 4200-P Portable, and 701-DL Topside Processors, tabular
troubleshooting guides are provided in T
ABLE 5-1, TABLE 5-2, and TABLE 5-3, respectively.
These troubleshooting guides identify some symptoms that could occur, and present one or more possible
causes, along with the recommended corrective action for each issue. Perform the corrective action for
any given symptom in the order of possible causes, which generally corresponds to the degree of
troubleshooting difficulty, from the simple to the more complex.
Detailed information for the Tow Vehicle is provided in 5.5
TOW VEHICLE TROUBLESHOOTING GUIDE.
Before proceeding with any corrective action, verify that the topside processor is plugged into an
appropriate AC or DC power source and that the processor is switched on.
NOTE: Be sure to also verify all the cables on the topside processor, and
the tow vehicle are mated and are not loose or damaged. Most causes of
operational or performance problems are a result of poor connections.
5.4.1 4200 Rack Mount Topside Processor Troubleshooting Guide
SYMPTOM
PROBABLE CAUSE
CORRECTIVE ACTION
The green SYSTEM
indicator on the
topside processor
does not illuminate
when the processor
is turned on.
The POWER switch is
not turned on
Verify the POWER switch on the back panel is on.
No AC Power
Verify the topside processor is connected to AC power.
Check the AC power source.
The indicator is not
operating
Open the topside processor and check the indicator and
wiring.
The red HARD DISK
indicator on the
topside processor
does not flash when
the processor is
turned on.
The operating system is
not booting
Open Topside Processor and verify the 500-GB hard drive
is connected to power, and the ribbon cable is properly
plugged into the CPU board.
The indicator is not
operating
Open the topside processor and check the indicator and
wiring.
The red TOWFISH
indicator on the
topside processor
The TOWFISH POWER
switch is not switched
on
Verify that the TOWFISH POWER switch was pressed and
wait 10 seconds for the indicator to light.
