5-1
SECTION 5: TROUBLESHOOTING
By following the instructions in the previous sections and performing regular maintenance, the user
should seldom encounter issues with the 4200 Series Side Scan Sonar System. If problems do occur,
however, this section will help users diagnose and fix simple issues. It includes basic troubleshooting
techniques, along with connector pin-out and wiring information, to assist in identifying and correcting
possible setup or operational problems.
If the customer encounters more serious issues or if the techniques below fail to address the problem,
please contact E
DGETECH CUSTOMER SERVICE.
5.1 Restoring the Operating System
The 4200 Rack Mount Topside Processor contains a 500 GB hard drive for both the operating system and
the application software. A separate 2 TB hard drive is included for data recording.
The hard drive can be backed up and restored using the supplied USB in the unlikely event of its failure.
For instructions on how to restore the operating system, refer to APPENDIX B: Backup and Restore.
5.2 Disassembling and Reassembling the Tow Vehicle
The procedures below describe how to disassemble and reassemble a tow vehicle to access and remove
the electronics chassis. The tools required are a 5-mm Allen wrench, a Phillips screwdriver, and a pair of
needle-nosed pliers.
WARNING!
High voltages that can cause injury or death are present in the tow
vehicle. Turn off the topside processor and disconnect the tow cable
before disassembling the tow vehicle.
CAUTION!
Opening the electronics chassis may void the user’s warranty unless
preapproved by EdgeTech. Contact EDGETECH CUSTOMER SERVICE before
opening the chassis.
