3-5
Figure 3-1: 4200 Rack Mount Topside Processor Rear Panel
SEA CABLE
connector
EXT TRIG
connector
COM 1-NAV
connector
COM 3
connector
MARK
connector
VAC INPUT
connector
POWER
switch
MONITOR
connector
USB
connectors
ETHERNET
connector
