3-2
4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL 0004842_REV_N
• Laptop computer
• Laptop computer power supply
• AC power cable
• DC power/Ethernet cable
• Software USB Drive
• Tow Vehicle Accessories Kit
For a system that includes a 701-DL Digital Link:
• 701-DL Digital Link
• 4200-SP or 4200-MP,
• AC power cord
• Ethernet patch cable
• Software CDs
• Tow Vehicle Accessories Kit
In addition to the listed components, the following optional items may be included:
• Tow cable
• Test cable
After unpacking the system components, safely store the shipping containers, including any packing
materials, for later use. When transporting or storing the system, pack all items in their original shipping
containers, and in the same manner in which they were originally shipped. Store the system in a dry
environment when not in use.
3.2 Power Requirements
The power requirements for the 4200 Series Topside processors are 180–140 or 90–260 VAC, 50/60 Hz,
and are auto-switching. The 4200-P Portable Topside Processor can also be powered with 18–36 VDC.
3.2.1 Use of an Uninterrupted Power Supply
The AC power source should be continuously free of high amplitude, high-frequency transients, as this
type of interference could degrade performance or damage the equipment. An uninterrupted power
supply (UPS) with power surge protection is recommended for powering the equipment. However,
whether or not a UPS is used, do not use the same AC power source as one being used to power electric
motors on the survey vessel, such as pumps and winches. Also, do not use switching type battery chargers
or DC to AC converters with square wave outputs.
