Edgetech 4200 - Processor Troubleshooting Guides; Rack Mount Processor Troubleshooting; Portable Processor Troubleshooting; 701-DL Digital Link Troubleshooting

2-7
Figure 2-3: 4200-P Portable Topside Processor Chassis
Net Burner board
24 VDC Power
Supply
ADSL modem
board
Wireless Router
board
AC Line Filter
Power board
