3.5.3 701-DL Digital Link Controls and Indicators
The 701-DL Digital Link includes controls and indicators on the front and back panels, as shown in FIGURE
3-4.
The 701-DL Digital Link controls and indicators are as follows:
LINE: Rocker switch. Switches AC power to the POWER switch on the front panel of the
701-DL Digital Link. This switch can be left in the on position at all times.
POWER: Rocker switch. Turns on the 701-DL Digital Link.
(switch)
POWER: Green indicator. Illuminated when the 701-DL Digital Link is on.
(indicator)
LAN: Green indicator. Flashes continuously when an Ethernet connection is
established.
LINK: Green indicator. Flashes while the 701-DL Digital Link is establishing a reliable
communications link with the tow vehicle. Illuminates continuously when a
reliable communications link with the tow vehicle is established.
FISH POWER: Red indicator. It is illuminated when the 701-DL Digital Link is on, and the tow
vehicle is properly connected to it.
NOTE: The 701-DL Digital Link will automatically switch off power to the
tow vehicle if the two remain disconnected for an extended period. The
power will also shut off if an overcurrent or undercurrent condition exists.
To reactivate the power to the tow vehicle, turn the POWER switch off
and then on again.
