Edgetech 4200 User Manual

A-1
APPENDIX A: DIAGRAMS
Configuration of the ADSL modems in the topside processor and in the tow vehicle is for advanced users
only. The ADSL modem in the topside processor is a Zoom ADSL X3 Modem Model 5560, and in the tow
vehicle, a Zoom ADSL X5 Modem Model 5654. The Model 5560 is a combination modem, router, and
Ethernet port. The Model 5654 is a combination modem, router, and 4-port switch.
NOTE: Both the X3 and X5 ADSL Modems should be reset to their default
manufacturer’s configuration before making any configuration changes.
To reset the modems, first, turn them on and then press the RESET button
on the back of the device for at least 10 seconds.
A.1 Advanced Users Setup Guides
The following setup guides for the Zoom ADSL X3 Modem Models 5560A, 5560, and 5654 are for advanced
users only.
A.1.1 Zoom ADSL X3 Modem Model 5560A Setup
To set up the Zoom ADSL X3 Modem Model 5560A:
1. Open your web browser and enter http://10.0.0.2 or http://192.9.0.22 to connect to the modem.
2. Login with username = admin and password = zoomadsl.
3. From the Basic Setup page, choose the MANUALLY option to configure the modem.
4. From the Advanced Setup page, click WAN Settings, make the following WAN configuration
changes, and then click Save Changes:
Encapsulation = 1483 Bridged IP LLC
VPI = 0
VCI = 35
Bridge = Enabled
5. From the Advanced Setup page, click LAN Settings, make the following LAN configuration changes,
and then click Save Changes:
Conf. LAN IP Address = 192.9.0.22
Conf. LAN Network Mask = 255.255.255.0
6. Open a web page to http://192.9.0.22 and log in as user = admin,
password = zoomadsl.
