A-19
20. Click Confirm.
The settings are saved, and the modem is rebooted:
21. Wait 60 seconds. The browser will reconnect to the modem.
During the reboot process, the Modem LINK LED turns off, and after a successful reboot, it starts
flashing again. The web browser will open and reconnect to http://192.9.9.0.22 to connect to the
new modem address.
22. Verify the login succeeds and that the Basic Setup page is displayed, then close your web browser.
A.2.5 Remove Temporary Host IP Address
To remove the temporary host IP address again after configuration, follow the steps in “Adding a
Temporary Host IP Address” on page C-6 up to Step 5 to open the Advanced TCP/IP Settings window. Then
select the entry for IP Address = 10.0.0.99 and click Remove to delete it from the list. Click OK until done.
