4200 SIDE SCAN SONAR SYSTEM USER HARDWARE MANUAL 0004842_REV_N
5.2.1 Disassembling the Tow Vehicle
Figure 5-1: Removing the Tail Fins from the Tail Cone
To disassemble the tow vehicle:
1. Place the tow vehicle on a clean, dry, and flat surface.
2. Loosen the thumbscrew at the back of the tail cone, then remove the two tail fins, one at a time.
Tail fins (2)
Thumb screw
Tail cone
