2-16
Figure 2-9: Tow Vehicle Electronics Chassis
CPU board
Power Distribution
board
ADSL modem
board
Pressure
transducer
SSL Power
Amplifier board
(Starboard)
SSH Power
Amplifier board
(Starboard)
SSL Power
Amplifier board
(Port)
SSH Power
Amplifier board
(Port)
Space for optional
Responder board
Side Scan board / DDC for
300/600 kHz and 300/900 kHz
configurations
Sonar Interface
board
T/R Switch board
HPR &
Compass
module
