3-8
Figure 3-3: 4200-P Portable Topside Side Panel
POWER
switch
SYSTEM
READY
indicator
TOWCABLE
connector
LINK OK
indicator
DC INPUT
ETHERNET
connector
POWER
indicator
5A/250V
fuse
FISH POWER
indicator
AC INPUT
connector
EXT TRIGGER
connector
