3-15
Figure 3-6: Topside Processor Cables
AC power cable (for
4200-P Portable
Topside Processor only)
DC power/Ethernet
cable (for 4200-P
Portable Topside
Processor only)
Ethernet patch cable
(for 701-DL only)
AC power cord
