3-6
Figure 3-2: 4200 Rack Mount
SYSTEM
POWER
indicator
FISH POWER switch
FISH POWER
indicator
Removable
1-TB drive
SYSTEM
POWER
switch
HDD
indicator
USB
connectors
RESET
switch
DVD drive
