Power Supplies
24Q Library
1. Fan Vent
2. Power connector (110-220 V AC
48Q Library
1. Fan Vent
2. Power connector (110-220 V AC 
3. LED (blue) - AC power 
4. LED (amber) -Fan Failure 
5. LED (green) - Power
