97 Installation and Service Guide: Printer Controller EB-34
Troubleshooting
Motherboard, including components and traces, appears undamaged, and no
foreign objects are evident.
CPU is present, well-seated, and appears undamaged.
CPU cooling assembly is well-aligned and firmly attached.
Each fan required (including fan cable) is well-positioned (not upside down),
powered by the correct motherboard connector, and appears undamaged.
Boards required on the motherboard are present, well-seated, and in the
correct slots.
Each DIMM is well-seated.
Battery is installed.
BIOS is well seated.
Motherboard, page 46
Each DIMM is well-seated.
DIMM edge connectors are not oxidized.
DIMM(s) for EB-34, page 56
Copier interface board is:
Present
Well-seated and installed in the correct slot5
Appears undamaged
Copier interface board, page 43
User Interface Board (UIB) is:
Present
Correctly attached to its bracket
Appears undamaged
UIB cable is:
Present
Firmly connected in the correct connector on the motherboard and the back of
the UIB
Appears undamaged
User Interface Board page 44
CPU is:
Present
Well-seated
Appears undamaged
The CPU cooling assembly is:
Well-aligned
Firmly attached
CPU with cooling assembly, page 58
Fan is:
Properly positioned (not backwards)
Installed in the correct connector
Fan, fan cable, cable connector, and mating connector appear undamaged
Chassis fan, page 62
Table 2: Verifying the system
Conditions to verify Part and additional page references
