EMC VNX VG2 User Manual

EMC VNX VG2/VG8 Gateway Configuration Setup Guide
208
NAS Install Options
EMC CONFIDENTIAL
c. The Configure TCP/IP dialog box appears (Figure 118). To make a selection,
tab to a checkbox and press Enter. Valid selections include:
–IPv4
or
–IPv4 and IPv6 (you must select both checkboxes!)
Tab to Ok and press Enter.
Figure 118 Configure TCP/IP
Note: If you select IPv4 and IPv6, you will be prompted to enter IP addresses in the
IPv6 format.
d. Enter the port IP address, netmask, default gateway IP address, and primary
nameserver IP address (Figure 119). Tab to Ok and press Enter.
Figure 119 Example of Configure TCP/IP window
The system displays the Configure Network dialog box (Figure 120 on
page 209).
