Installing the Hardware
c. Verify that the Power and Status LEDs (shown in Figure 18) on both Fibre
Channel switches are steady green.
Figure 18 Fibre Channel switch, rear (port side) view
9. Remove the bezel from the front of the management server.
10. On the front of the management server (Figure 19), verify that the power LED is
illuminated.
If the LED is not on, press the power button.
Figure 19 Management server power button and LEDs
11. Replace the management server bezel.
Zep-034
Status LED
Power LED
Zep-015
Power LED
Power button
