Figure 57 Serial cabling in a dual-engine configuration
Zep-005_sm
Engine1
UPS A
UPS B
Engine 2
038-003-894
40 in.
038-003-894
40 in.
038-003-682
12 in.
038-003-682
12 in.
038-003-682
12 in.
038-003-682
12 in.
