EMC VPLEX with GeoSynchrony 4.1 Installation and Setup Guide
44
Setting up VPLEX
Output example (partial):
/clusters/cluster-1/storage-elements/extents:
extent_Symm1707_1000_1 extent_Symm1707_1001_1 extent_Symm1707_1002_1 extent_Symm1707_1003_1
extent_Symm1707_1004_1 extent_Symm1707_1005_1 extent_Symm1707_1006_1 extent_Symm1707_1007_1
extent_Symm1707_1008_1 extent_Symm1707_1009_1 extent_Symm1707_100A_1 extent_Symm1707_100B_1
extent_Symm1707_100C_1 extent_Symm1707_100D_1 extent_Symm1707_100E_1 extent_Symm1707_100F_1
extent_Symm1707_1010_1 extent_Symm1707_1011_1 extent_Symm1707_1012_1 extent_Symm1707_1013_1
extent_Symm1707_1014_1 extent_Symm1707_1015_1 extent_Symm1707_1016_1 extent_Symm1707_1017_1
extent_Symm1707_1018_1 extent_Symm1707_1019_1 extent_Symm1707_101A_1 extent_Symm1707_101B_1
extent_Symm1707_101C_1 extent_Symm1707_101D_1 extent_Symm1707_101E_1 extent_Symm1707_101F_1
extent_Symm1707_1020_1 extent_Symm1707_1021_1 extent_Symm1707_1022_1 extent_Symm1707_1023_1
extent_Symm1707_1024_1 extent_Symm1707_1025_1 extent_Symm1707_1026_1 extent_Symm1707_1027_1
extent_Symm1707_1028_1 extent_Symm1707_1029_1 extent_Symm1707_102A_1 extent_Symm1707_102B_1
extent_Symm1707_102C_1 extent_Symm1707_102D_1 extent_Symm1707_102E_1 extent_Symm1707_102F_1
extent_Symm1707_1030_1 extent_Symm1707_1031_1 extent_Symm1707_1032_1 extent_Symm1707_1033_1
extent_Symm1707_1034_1 extent_Symm1707_1035_1 extent_Symm1707_1036_1 extent_Symm1707_1037_1
extent_Symm1707_1038_1 extent_Symm1707_1039_1 extent_Symm1707_103A_1 extent_Symm1707_103B_1
5. Type the following commands to create the RAID device:
cd /clusters/cluster-1/devices
local-device create <device_name> -g[raid-0|raid-1|raid-c] -e
<extent>,<extent>
6. Type the following commands to create the virtual volume:
cd /clusters/cluster-1/virtual-volumes
create -r <device_name>
7. Type the following command to list the initiator ports:
ll /clusters/cluster-1/exports/initiator-ports
Output example (partial):
8. Type the following commands to register each initiator port:
cd /clusters/cluster-1/exports/initiator-ports
export initiator-port register -i <initiator_port> -p
<portWWN|nodeWWN>
Name port-wwn node-wwn type Target Port Names
------------ ------------------ ------------------ ------- --------------------------
UNREGISTERED-0x10000000c866fff2 0x10000000c866fff2 0x20000000c866fff2 default P000000003CA00165-A0-FC00,
P000000003CA00183-A0-FC00,
P000000003CB00165-B0-FC00,
P000000003CB00183-B0-FC00
UNREGISTERED-0x10000000c866fff3 0x10000000c866fff3 0x20000000c866fff3 default P000000003CA00165-A0-FC01,
P000000003CA00183-A0-FC01,
P000000003CB00165-B0-FC01
UNREGISTERED-0x10000000c866ffec 0x10000000c866ffec 0x20000000c866ffec default P000000003CA00165-A1-FC00,
P000000003CA00183-A1-FC01,
P000000003CB00165-B1-FC00,
P000000003CB00183-B1-FC01
UNREGISTERED-0x10000000c866ffed 0x10000000c866ffed 0x20000000c866ffed default P000000003CA00165-A0-FC01,
P000000003CA00183-A1-FC00,
P000000003CB00165-B0-FC01,
P000000003CB00183-B0-FC01,
P000000003CB00183-B1-FC00
