9.2 Cleaning the Optional 3M or Triple Filter
1. Turn off power and unplug the power cord.
2. Remove the air filters from the unit.
3. Remove the 3M and/or Triple filters from the unit, Figure 9-8.
Figure 9-8 Removing 3M/Triple filters from indoor unit
4. Clean the filters with a vacuum cleaner.
5. Insert the 3M and/or Triple filters in the unit, Figure 9-9.
Figure 9-9 Replacing 3M/Triple filters in the indoor unit
6. Replace the air filters.
7. Check the sides of the front cover to make sure the air filters are installed correctly.
Type1
Type2
Type1
Type2
