Installation Set-up and System Start-up
Liebert
®
SRC
™
User Manual 86
7.2 Running Test Mode
1. On the thermostat, press for at least 3 seconds.
The function code blinks in the lower-middle of the display.
07 Master setting
00 = Slave
01 = Master
(only “Plus 1 series models)
00 = Group
01 = Single
08 Override setting
00 = Slave
01 = Master
09 Dry contact
00 = Auto-off
01 = Auto-on
12 Celsius/Fahrenheit
00 = Celsius
01 = Fahrenheit
18 Emergency heater
Select mode:
00 = not used
01 = use
Low-ambient heating operation:
0 = not used
1 = compressor off 0°F (–18°C)/ on 5°F (–15°C)
2 = compressor off 5°F (–15°C)/ on 10°F (–12°C)
3 = compressor off 10°F (–12°C)/ on 15°F (–9°C)
Fan speed:
0 = fan off
1 = fan on
20 Plasma
00 = not installed
01 = installed
21 Electric heater
22 Humidifier
23 Elevation grill
24 Ventilation kit
25 Auxiliary heater
31
Settings temperature
range
00 = 60~86°F / 16~30°C
01 = 40~99°F / 4~37.5°C
NOTE
Before running test mode, make sure of the following:
• Leak testing is complete and there are no leaks.
• Air purge/evacuation is complete and successful.
• All tubing, piping, and wiring are properly connected.
NOTE
A press less than 3 seconds enters “user” settings mode.
Table 7-1 General unit functions—Installer set-up codes (continued)
Function
Code Description Value
Some menu options and functions may not be displayed or the menu name may be different
depending on your system and model.
