Installation Set-up and System Start-up
89 Liebert
®
SRC™ User Manual
7.6 Setting the Ceiling Height
Refer to Table 7-1 for the specific function-setting values.
1. On the thermostat, press for at least 3 seconds.
The function code blinks in the lower-middle of the display.
2. Press repeatedly to select the function code.
3. Press , to select the Value, then use to select the setting. Refer to Table 7-3 for
descriptions of the ceiling-height settings.
4. Press .
The setting is saved.
5. Press to exit installer setting mode.
7.7 Setting Fahrenheit/Celsius
Refer to Table 7-1 for the specific function-setting values.
1. On the thermostat, press for at least 3 seconds.
The function code blinks in the lower-middle of the display.
2. Press to select the function code.
3. Press , to select Value, then use to select the setting.
4. Press .
The setting is saved.
5. Press to exit installer setting mode.
NOTE
A press less than 3 seconds enters “user” settings mode.
Table 7-3 Ceiling-height setting options
Value Function
01 Low Decrease indoor air-flow rate 1 step from standard level.
02 Medium Set indoor air-flow rate as standard level.
03 High Increase indoor air-flow rate 1 step from standard level.
04 Very high Increase indoor air-flow rate 2 steps from standard level.
NOTE
If there is no button input for 25 seconds, set-up mode is automatically exited.
If you exit without pressing , your settings are not saved.
NOTE
A press less than 3 seconds enters “user” settings mode.
NOTE
If there is no button input for 25 seconds, set-up mode is automatically exited.
If you exit without pressing , your settings are not saved.
