Emerson Process Management GmbH & Co. OHG1-8
X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
1.7 Technical Data
Site of installation
Humidity (non condensing) < 90 % r. h. at +20 °C (68 F)
< 70 % r. h. at +40 °C (104 F)
Pollution degree 2
Installation category I I
Altitude 0 to 6560 ft (2000 m) above sea level
Sourrounding atmosphere Analyzers must not be operated in
corrosive atmosphere.
Power supply
Rated input voltage 100 - 240 V
50/60 Hz, wide range input
Power supply voltage fl uctuations are
not to exceed +/- 10 % of the nominal
supply voltage!
Input voltage range 85 - 264 V
, 47 - 63 Hz
Nominal input current
standard 1.3 - 0.7 A max.
with temperature control 3 - 1.5 A max.
General Purpose Compliances
Electrical safety CAN / USA CSA-C/US, based on
CAN/CSA-C22.2 No. 61010-1-04 /
UL 61010-1, 2
nd
Edition
Europe CE, based on EN 61010-1
Electromagnetic compatibility
Europe CE, based on EN 61326
other NAMUR
