Emerson ROSEMOUNT Xstream X2 Series User Manual

Emerson Process Management GmbH & Co. OHG 2-17
2
Installation
X-STREAM X2FD
Instruction Manual
HASXMDE-IM-EX
01/2015
2.5 Installation - Electrical
Installation with conduits
Ensure all required parts are available:
Adaptors, suitable conduits, compound and
plugs for not used entries (see accessory kit).
Install the required number of adaptors into
the related cable entries:The 3 rear entries
are reserved for signal cables, the fi rst one is
for the power cord.
Tightening torque:
max. 354 in.lb / 40 Nm!
Ensure the explosionproof seal is placed
at the analyzer enclosure or within 2“ from
enclosure.
All cables need to be fed properly through
conduits when entering the instrument and
connected to the terminals (
warning
notes, page 2-8).
To seal the cable entries proceed according to
the installation instruction given in the related
conduits manufacturer documentation.
Keep the original manufacturer‘s
documentation available for fu-
ture reference!
Seal unused entries utilizing the fl ameproof
certifi ed plugs.
All signal cables are to be connected via
screw terminals, except the optional ethernet
connector, located inside the analyzer.
Preparation of signal cables
Supported wire cross sections: 0,14 to 1,5 mm
2
(26 to 15 AWG) ,
no need to use wire end sleeves
Cable skinning length: 5 mm (0.2 inch)
Screw thread: M 2
Tightening torque, min: 0,25 Nm (2.3 in.lb)
Installation with cable glands
Ensure all required parts are available:
Cable glands and plugs for not used entries.
Verify the provided cable gland is designed
for your type of cable (e. g. armoured, non-;
diameter), see marking on the cable gland.
Install the required number of cable glands
according the manufacturers instruction into
the related cable entry:The 3 rear entries are
reserved for signal cables, the fi rst one is for
the power cord.
Tightening torque:
max. 354 in.lb / 40 Nm!
All cables need to be fed properly through the
cable glands when entering the instrument
and connected to the terminals ( warning
notes, page 2-8).
To seal the cable entries proceed according to
the installation instruction given in the related
cable glands manufacturer documentation.
Keep the original manufacturer‘s
documentation available for fu-
ture reference!
Seal unused entries utilizing the fl ameproof
certifi ed plugs.
