Table 3-4 Paralleled SPMA 690V motor drive ratings (500V to 690V ±10%)
Table 3-5 SPMD 200V drive ratings (200V to 240V ±10%) based on AC supply voltage
*SPMD12X1 to 12X3 ratings apply with the rectifier docked and undocked.
**SPMD12X4 rating with the rectifier docked. The overload rating for the SPMD12X4 is only available if the ambient temperature is 35°C or lower.
***SPMD12X4 rating with the rectifier undocked. The maximum continuous output current and overload rating for the SPMD12X4 is only available if
the ambient temperature is 35°C or lower.
Table 3-6 Paralleled SPMD 200V motor drive ratings (200V to 240V ±10%) based on AC supply voltage
Paralleled SPMA modules
Normal Duty Heavy Duty
Required
output sharing
choke
Maximum
continuous
output
current
Peak
current
Nominal
motor
power
at 690V
Nominal
motor
power
at 575V
Maximum
continuous
output
current
Open
loop
peak
current
Closed
loop
peak
current
Nominal
motor
power
at 690V
Nominal
motor
power
at 575V
AAkWhp AAAkWhp
2 x SPMA16X1 237 261 250 250 190 244 284 200 200 1 x OTL611
2 x SPMA16X2 273 300 280 300 237 305 356 250 250 1 x OTL612
3 x SPMA16X1 356 391 355 400 285 366 427 300 300 3 x OTL601
3 x SPMA16X2 410 451 450 450 356 457 534 355 400 3 x OTL602
4 x SPMA16X1 475 522 500 500 380 488 569 400 400 4 x OTL601
4 x SPMA16X2 547 601 560 600 475 610 712 500 500 4 x OTL602
5 x SPMA16X1 593 653 610 600 475 610 712 500 500 5 x OTL601
5 x SPMA16X2 684 752 710 700 593 763 890 610 600 5 x OTL602
6 x SPMA16X1 712 783 710 800 570 732 854 610 600 6 x OTL601
6 x SPMA16X2 820 902 875 900 712 915 1068 710 800 6 x OTL602
The Unidrive SPMD can be connected to its rectifier module in two ways, directly above the inverter (docked) or independently mounted in
different vertical planes (undocked). Changes in the flow of air mean that the ratings are different for the two mounting methods for SPMD12x4.
For details on docking, refer to section 5.6 Docking a Unidrive SPMC/U to an SPMD on page 39.
Model
Normal Duty Heavy Duty
Required
rectifier
Required
input line
reactor
External 24V
current
consumption
Maximum
continuous
output
current
Peak
current
Nominal
motor
power at
230V
Nominal
motor
power at
230V
Maximum
continuous
output
current
Open
loop
peak
current
Closed
loop
peak
current
Nominal
motor
power
at 230V
Nominal
motor
power at
230V
AAkWhpA AAkWhp
A
SPMD12X1* 192 211 55 75 156 201 234 45 60
1 x
SPMU1402
1 x
INL401
3.3
SPMD12X2* 248 272 75 100 192 247 288 55 75
SPMD12X3* 312 343 90 125 250 322 375 75 100
1 x
INL402
SPMD12X4** 335 365 90 125 290 374 435 90 125
SPMD12X4*** 350 385 110 150 290 374 435 90 125
When using an SPMU a separate soft start circuit must be
provided for the DC bus. Refer to Figure 4-6 on page 30 and
section 6.5 Resistor sizing for Unidrive SPMU softstart on
page 70.
Paralleled SPMD modules
Normal Duty Heavy Duty
Required
rectifier
Required
line
reactor
Required
output
sharing
choke
Maximum
continuous
output
current
Peak
current
Nominal
motor
power at
230V
Nominal
motor
power at
230V
Maximum
continuous
output
current
Open
loop
peak
current
Closed
loop
peak
current
Nominal
motor
power
at 230V
Nominal
motor
power at
230V
AAkWhp AAAkWhp
2 x SPMD12X1 364 401 110 150 296 381 444 90 125
1 x
SPMU2402
1 x INL411
1 x
OTL411
2 x SPMD12X2 471 518 132 200 364 468 546 110 150 1 x INL411
1 x
OTL412
2 x SPMD12X3 592 652 160 250 475 610 712 150 200
1 x
INL412
1 x
OTL413
2 x SPMD12X4 636 700 200 250 551 708 826 160 200
1 x
INL412
1 x
OTL414
NOTE
CAUTION
The Unidrive SPMD can be connected to its rectifier module in two ways, directly above the inverter (docked) or independently mounted in
different vertical planes (undocked). Changes in the flow of air mean that the ratings are different for the two mounting methods for SPMD14x4.
For details on docking, refer to section 5.6 Docking a Unidrive SPMC/U to an SPMD on page 39.
NOTE
