Figure 5-17 Surface mounting the Unidrive SPMD with SPMC/U (rectifier) and docking kit
N
A current derating must be applied to the Unidrive SPMD1404 when
docked with the Unidrive SPMC/U. Details can be found in section
14.1.1 Power and current ratings (Derating for switching frequency and
temperature) on page 263.
310.1mm (12.209in)
18.3mm (0.720in)
18.3mm (0.720in)
1145.1mm
(45.083in)
297.4mm (11.709in)
1145.1mm
(45.083in)
25.7 0.5mm
(1.012 0.020in)
±
±
∅
8.5mm
(0.335in)
258.6 0.5mm
(10.181 0.020in)
±
±
258.6 0.5mm
(10.181 0.020in)
±
±
145.3 0.25mm
(5.720 0.010in)
±
±
90.3
0.25mm
(3.555
0.010in)
±
±
380.5 0.25mm
(14.980 0.010in)
±
±
777.3 0.25mm
(30.602 0.010in)
±
±
1163.8 0.5mm
(45.819 0.020in)
±
±
∅
8.5mm
(0.335in)
NOTE
