14.2.1 EMC filter ratings
Table 14-44 Optional external EMC filter details
N
1. 1MΩ in a A connection between phases, with the A point connected by a 680kΩ resistor to ground (i.e. line to line 2MΩ, line to ground 1.68MΩ)
2. Line to line 3.6MΩ, line to ground 3.3MΩ
14.2.2 Overall EMC filter dimensions
Table 14-45 Optional external EMC filter dimensions
14.2.3 EMC filter torque settings
Table 14-46 Optional external EMC Filter terminal data
CT part
number
Manufacturer
Maximum continuous
current
Voltage
rating
V
IP
rating
Power
dissipation
at rated
current
W
Ground leakage
Discharge
resistors
Balanced supply
phase-to-phase and
phase-to-ground
mA
1 phase
open
circuit
mA
@ 40°C
(104°F)
A
@ 50°C
(122°F)
A
4200-6603
Schaffner
260 237 480
00
14.2 41 219
See Note 1
4200-6604 160 690 88.5 296
4200-6315 340 480 52 293
4200-6316 200 690 72 406
4200-6601
Epcos
260 195 480 13 45 220
See Note 2
4200-6602 160 120 690 5 60 310
4200-6313 340 255 480 74 375
4200-6314 200 150 690 79 392
4200-6801 600 546
500
66.96 <6
4200-6802 1000 910 99 <6
4200-6803 1600 1456 168.96 <6
NOTE
CT part number Manufacturer H W D
4200-6603
Schaffner 136 mm (5.354 in)
295 mm (11.614 in)
230 mm (9.055 in)
4200-6604 357 mm (14.055 in)
4200-6315
339 mm (13.346 in)
4200-6316
4200-6601
Epcos
147 mm (5.787 in) 364 mm (14.330 in)
230 mm (9.055 in)
4200-6602
4200-6313
149 mm (5.866 in) 339 mm (13.346 in)
4200-6314
4200-6801 116mm (4.57in) 440±2.5 mm (17.32±0.1 in) 260 mm (10.24 in)
4200-6802
166mm (6.54in)
460±2.5 mm (18.11±0.1 in)
300 mm (11.81 in)
4200-6803 590±3 mm (23.23±0.12 in)
CT part number Manufacturer
Power connections Ground connections
Max torque Ground stud size Max torque
4200-6603
Schaffner 12 N m (8.8 lb ft)
M10
25 N m (18.4 lb ft)
4200-6604
4200-6315
4200-6316
4200-6601
Epcos 10 N m (7.4 lb ft)
10 N m (7.4 lb ft)
4200-6602
4200-6313
4200-6314
4200-6801
4200-6802
M12 15.5 N m (11.4 lb ft)
4200-6803
