13.15.3 Automation module category
Figure 13-29 SM-I/O Plus analog logic diagram
X.41
T9 Analog
input 1
scaling
??.??
Any
unprotected
variable
parameter
??.??
X.43
T9 Analog
input 1
destination
x(-1)
X.42
T9 Analog
input 1 invert
X.40
T9 Analog input 1
0.XX
0.XX
Key
Read-write
(RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
X.45
??.??
Any
unprotected
variable
parameter
??.??
X.47
x(-1)
X.46
X.44
T10 Analog
input 2 invert
T9 Analog
input 1
T10 Analog input 2
T10 Analog
input 2
T10 Analog
input 2
destination
T10 Analog
input 2
scaling
T12 Analog
output 1
