164 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
Table 13-5 Maximum motor rated current
Up to 10 SPMAXXXX or SPMDXXXX drive modules can be connected
in parallel to make a larger drive, provided all power modules are of the
same type, and have the same voltage and current ratings. The currents
are then defined as follows:
Current scaling (K
c
)
K
c
is the sum of K
c
for all the modules.
Maximum Heavy Duty current rating
Maximum Heavy Duty current rating = 0.95 x the sum of maximum
Heavy Duty current rating for all the modules.
Maximum Normal Duty rated current
Maximum Normal Duty rated current = 0.95 x the sum of maximum
Normal Duty rated current for all the modules.
Model
K
C
Maximum Heavy Duty
current rating (Pr 11.32)
A
Maximum Normal
Duty current rating
A
SPMD12X1 133.7 156 192
SPMD12X2 164.5 192 248
SPMD12X3 214.2 250 312
SPMD12X4 248.5 290 350
SPMA14X1 154.2 180 202
SPMA14X2 180.0 210 236
SPMD14X1 154.2 180 202
SPMD14X2 180.0 210 236
SPMD14X3 205.7 240 290
SPMD14X4 248.5 290 330
SPMA16X1 85.7 100 125
SPMA16X2 107.1 125 144
SPMD16X1 85.7 100 125
SPMD16X2 107.1 125 144
SPMD16X3 123.4 144 168
SPMD16X4 144.0 168 192
