172 Unidrive SPM User Guide
www.controltechniques.com Issue Number: 3
Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
2.01 Post ramp reference ±SPEED_FREQ_MAX Hz/rpm
RO Bi NC PT
2.02 Ramp enable {0.16}
OFF (0) or On (1) On (1) RW Bit US
2.03 Ramp hold OFF (0) or On (1) OFF (0) RW Bit US
2.04 Ramp mode select {0.15}
FASt (0)
Std (1)
Std.hV (2)
FASt (0)
Std (1)
Std (1) RW Txt US
2.06 S ramp enable OFF (0) or On (1) OFF (0) RW Bit US
2.07 S ramp acceleration limit
0.0 to 300.0
s
2
/100Hz
0.000 to 100.000
s
2
/1000rpm
3.1 1.500 0.030 RW Uni US
2.08 Standard ramp voltage 0 to DC_VOLTAGE_SET_MAX V
200V drive: 375
400V drive: EUR> 750
USA> 775
575V drive: 895
690V drive: 1075
RW Uni RA US
2.10 Acceleration rate selector 0 to 9 0 RW Uni US
2.11 Acceleration rate 1 {0.03}
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.12 Acceleration rate 2
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.13 Acceleration rate 3
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.14 Acceleration rate 4
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.15 Acceleration rate 5
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.16 Acceleration rate 6
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.17 Acceleration rate 7
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.18 Acceleration rate 8
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
5.0 2.000 0.200 RW Uni US
2.19 Jog acceleration rate
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
0.2 0.000 RW Uni US
2.20 Deceleration rate selector 0 to 9 0 RW Uni US
2.21 Deceleration rate 1 {0.04}
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.22 Deceleration rate 2
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.23 Deceleration rate 3
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.24 Deceleration rate 4
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.25 Deceleration rate 5
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.26 Deceleration rate 6
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.27 Deceleration rate 7
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.28 Deceleration rate 8
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
10.0 2.000 0.200 RW Uni US
2.29 Jog deceleration rate
0.0 to 3,200.0
s/100Hz
0.000 to 3,200.000
s/1,000rpm
0.2 0.000 RW Uni US
2.32 Acceleration select bit 0 OFF (0) or On (1) OFF (0) RW Bit NC
2.33 Acceleration select bit 1 OFF (0) or On (1) OFF (0) RW Bit NC
2.34 Acceleration select bit 2 OFF (0) or On (1) OFF (0) RW Bit NC
2.35 Deceleration select bit 0 OFF (0) or On (1) OFF (0) RW Bit NC
2.36 Deceleration select bit 1 OFF (0) or On (1) OFF (0) RW Bit NC
2.37 Deceleration select bit 2 OFF (0) or On (1) OFF (0) RW Bit NC
2.38 Inertia compensation torque
± 1,000.0 % RO Bi NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
