Emerson Unidrive SPM User Manual

Safety
Information
Introduction
Product
Information
System
configuration
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
Unidrive SPM User Guide 197
Issue Number: 3 www.controltechniques.com
Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
9.01 Logic function 1 output OFF (0) or On (1)
RO Bit NC PT
9.02 Logic function 2 output OFF (0) or On (1)
RO Bit NC PT
9.03 Motorized pot output ±100.00 %
RO Bi NC PT PS
9.04 Logic function 1 source 1 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.05
Logic function 1 source 1
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.06 Logic function 1 source 2 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.07
Logic function 1 source 2
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.08 Logic function 1 output invert OFF (0) or On (1) OFF (0) RW Bit US
9.09 Logic function 1 delay ±25.0 s 0.0 RW Bi US
9.10 Logic function 1 destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.14 Logic function 2 source 1 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.15
Logic function 2 source 1
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.16 Logic function 2 source 2 Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
9.17
Logic function 2 source 2
invert
OFF (0) or On (1) OFF (0) RW Bit US
9.18 Logic function 2 output invert OFF (0) or On (1) OFF (0) RW Bit US
9.19 Logic function 2 delay ±25.0 s 0.0 RW Bi US
9.20 Logic function 2 destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.21 Motorized pot mode 0 to 3 2 RW Uni US
9.22 Motorized pot bipolar select OFF (0) or On (1) OFF (0) RW Bit US
9.23 Motorized pot rate 0 to 250 s 20 RW Uni US
9.24 Motorized pot scale factor 0.000 to 4.000 1.000 RW Uni US
9.25 Motorized pot destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.26 Motorized pot up OFF (0) or On (1) OFF (0) RW Bit NC
9.27 Motorized pot down OFF (0) or On (1) OFF (0) RW Bit NC
9.28 Motorized pot reset OFF (0) or On (1) OFF (0) RW Bit NC
9.29 Binary sum ones input OFF (0) or On (1) OFF (0) RW Bit NC
9.30 Binary sum twos input OFF (0) or On (1) OFF (0) RW Bit NC
9.31 Binary sum fours input OFF (0) or On (1) OFF (0) RW Bit NC
9.32 Binary sum output 0 to 255 RO Uni NC PT
9.33 Binary sum destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
9.34 Binary sum offset 0 to 248 0 RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
