Parameter
Range(
Ú) Default(Ö)
Type
OL CL OL VT SV
14.01 PID control output
±100.00 %
RO Bi NC PT
14.02 PID main reference source Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
14.03 PID reference source Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
14.04 PID feedback source Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
14.05 PID reference source invert OFF (0) or On (1) OFF (0) RW Bit US
14.06 PID feedback source invert OFF (0) or On (1) OFF (0) RW Bit US
14.07 PID reference slew-rate limit 0.0 to 3,200.0 s 0.0 RW Uni US
14.08 PID enable OFF (0) or On (1) OFF (0) RW Bit US
14.09 PID optional enable source Pr 0.00 to 21.51 Pr 0.00 RW Uni PT US
14.10 PID proportional gain 0.000 to 4.000 1.000 RW Uni US
14.11 PID integral gain 0.000 to 4.000 0.500 RW Uni US
14.12 PID derivative gain 0.000 to 4.000 0.000 RW Uni US
14.13 PID upper limit 0.00 to 100.00 % 100.00 RW Uni US
14.14 PID lower limit ±100.00 % -100.00 RW Bi US
14.15 PID output scaling factor 0.000 to 4.000 1.000 RW Uni US
14.16 PID output destination Pr 0.00 to 21.51 Pr 0.00 RW Uni DE PT US
14.17 PID hold integrator enable OFF (0) or On (1) OFF (0) RW Bit NC
14.18 PID symmetrical limits enable OFF (0) or On (1) OFF (0) RW Bit US
14.19 PID main reference ±100.00 %
RO Bi NC PT
14.20 PID reference ±100.00 %
RO Bi NC PT
14.21 PID feedback ±100.00 %
RO Bi NC PT
14.22 PID error ±100.00 %
RO Bi NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
