SM-I/O Timer & SM-I/O Lite parameters
*See trip SLX.Er, Automation (I/O Expansion) module category on page 286.
Parameter
Range(
Ú)Default(Ö)
Type
SM-I/O
Lite Timer
x.01 Solutions Module ID 0 to 599
SM-I/O Timer: 203
SM-I/O Lite: 207
RO Uni PT US
99
x.02 Solutions Module software version 0.00 to 99.99 RO Uni NC PT 99
x.03 Current loop loss indicator OFF (0) or On (1) RO Bit NC PT 99
x.04 T5 digital input 4 state OFF (0) or On (1) RO Bit NC PT 99
x.05 T6 digital input 5 state OFF (0) or On (1) RO Bit NC PT 99
x.06 T7 digital input 6 state OFF (0) or On (1) RO Bit NC PT 99
x.07 Relay 1 state OFF (0) or On (1) RO Bit NC PT 99
x.14 T5 digital input 4 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.15 T6 digital input 5 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.16 T7 digital input 6 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.17 Relay 1 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.19 Real time clock daylight saving mode OFF (0) or On (1) OFF (0) RW Bit US 9
x.20 Digital I/O read word 0 to 255 RO Uni NC PT 99
x.24 T5 digital input 4 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US 99
x.25 T6 digital input 5 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US 99
x.26 T7 digital input 6 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US 99
x.27 Relay 1 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US 99
x.30 Real time clock update mode 0 to 2 0 RW Uni NC 9
x.34 Real time clock time: minutes.seconds 0.00 to 59.59 RW Uni NC PT 9
x.35 Real time clock time: days.hours 1.00 to 7.23 RW Uni NC PT 9
x.36 Real time clock time: months.days 0.00 to 12.31 RW Uni NC PT 9
x.37 Real time clock time: years 2000 to 2099 RW Uni NC PT 9
x.38 Analog input 1 mode
0-20 (0), 20-0 (1), 4-20.tr (2),
20-4.tr (3), 4-20 (4), 20-4 (5),
VOLt(6)
0-20 (0) RW Txt US 99
x.39 Analog output mode
0-20 (0), 20-0 (1), 4-20 (2), 20-4 (3),
VOLt (4)
0-20 (0) RW Txt US 99
x.40 Analog input 1 ±100.0% RO Bi NC PT 99
x.41 Analog input 1 scaling 0 to 4.000 1.000 RW Uni US 99
x.42 Analog input 1 invert OFF (0) or On (1) OFF (0) RW Bit US 99
x.43 Analog input 1 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US 99
x.48 Analog output 1 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US 99
x.49 Analog output 1 scaling 0.000 to 4.000 1.000 RW Uni US 99
x.50 Solutions Module error status* 0 to 255 RO Uni NC PT 99
x.51
Solutions Module software sub-version
0 to 99 RO Uni NC PT 99
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
