Unidrive SPM User Guide 237
Issue Number: 3 www.controltechniques.com
SM-I/O PELV parameters
*See trip SLX.Er, Automation (I/O Expansion) module category on page 286.
Parameter
Range(
Ú) Default(Ö)
Type
x.01 Solutions Module ID 0 to 599 204 RO Uni PT US
x.02 Solutions Module software version 0.00 to 99.99 RO Uni NC PT
x.03 T5 digital I/O 3 state OFF (0) or On (1) RO Bit NC PT
x.04 T6 digital I/O 4 state OFF (0) or On (1) RO Bit NC PT
x.05 T7 digital input 5 state OFF (0) or On (1) RO Bit NC PT
x.07 Relay 1 state OFF (0) or On (1) RO Bit NC PT
x.08 Relay 2 state OFF (0) or On (1) RO Bit NC PT
x.09 T3 digital I/O 1 state OFF (0) or On (1) RO Bit NC PT
x.10 T4 digital I/O 2 state OFF (0) or On (1) RO Bit NC PT
x.11 T3 digital I/O 1 invert OFF (0) or On (1) OFF (0) RW Bit US
x.12 T4 digital I/O 2 invert OFF (0) or On (1) OFF (0) RW Bit US
x.13 T5 digital I/O 3 invert OFF (0) or On (1) OFF (0) RW Bit US
x.14 T6 digital I/O 4 invert OFF (0) or On (1) OFF (0) RW Bit US
x.15 T7 digital input 5 invert OFF (0) or On (1) OFF (0) RW Bit US
x.16
Disable PELV User power
supply absent trip
OFF (0) or On (1) OFF (0) RW Bit US
x.17 Relay 1 invert OFF (0) or On (1) OFF (0) RW Bit US
x.18 Relay 2 invert OFF (0) or On (1) OFF (0) RW Bit US
x.19 Freeze flag OFF (0) or On (1) OFF (0) RW Bit US
x.20 Digital I/O read word 0 to 255 RO Uni NC PT
x.21 T3 digital I/O 1 source/destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.22 T4 digital I/O 2 source/destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.23 T5 digital I/O 3 source/destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.24 T6 digital I/O 4 source/destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.25 T7 digital input 5 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.27 Relay 1 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US
x.28 Relay 2 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US
x.29 T6 digital I/O 4 output select OFF (0) or On (1) On (1) RW Bit US
x.31 T3 digital I/O 1 output select OFF (0) or On (1) OFF (0) RW Bit US
x.32 T4 digital I/O 2 output select OFF (0) or On (1) OFF (0) RW Bit US
x.33 T5 digital I/O 3 output select OFF (0) or On (1) OFF (0) RW Bit US
x.38 Analog input 1 mode
0-20 (0), 20-0 (1), 4-20.tr (2), 20-4.tr (3),
4-20 (4), 20-4 (5)
0-20 (0) RW Txt US
x.39 Analog output mode 0-20 (0), 20-0 (1), 4-20 (2), 20-4 (3) 0-20 (0) RW Txt US
x.40 Analog input 1 level 0.0 to 100.0% RO Bi NC PT
x.41 Analog input 1 scaling 0.000 to 4.000 1.000 RW Uni US
x.42 Analog input 1 invert OFF (0) or On (1) OFF (0) RW Bit US
x.43 Analog input 1 destination Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni DE PT US
x.45 Analog output 2 scaling 0.000 to 4.000 1.000 RW Uni US
x.47 Analog output 2 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US
x.48 Analog output 1 source Pr 0.00 to Pr 21.51 Pr 0.00 RW Uni PT US
x.49 Analog output 1 scaling 0.000 to 4.000 1.000 RW Uni US
x.50 Solutions Module error status* 0 to 255 RO Uni NC PT
x.51
Solutions Module software sub-version
0 to 99 RO Uni NC PT
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
