Software Menus
Multi-channel unit:
Press
left to enter SELECT COMPONENT,
to change the settings for another channel.
6.2.3 Setup Menu
Ch1
 Valve Assignment 2of3
Span1 Valve: V1
Purge Time: 1 s
Span2 Valve: None
Purge Time: 0 s
Span3 Valve: None
Purge Time: 0 s
Span4 Valve: None

Purge Time:
0 s
Ch1
 Valve Assignment 3of3
Blowback Valve: None
Purge Time: 0 s
On the 2
nd
menu page, assign the span val-
ves, and specify their purge times for the
different ranges of the selected channel.
The 3
rd
menu page enables to assign a blow-
back valve, and specify its purge time for the
selected channel.
