Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG6-46
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6.2.3.3.1.1 Measurement Ranges Starts & Ends
6.2.3 Setup Menu
Select the range to be congured, and set
start and end concentrations.
Note!
For automatic or remote range control, all
ranges end values need to be different!
6.2.3.3.1.2 Measurement Autoranging
For each range select separately, if autoran-
ging is to be used (Yes) or not (No)
Specify the hysteresis for autoranging.
Accepted range: 1 ... 50 %
Alternatively specify switchover limits for each
range separately;
6-46.
Setup..
Measurement..
Ranges..
Starts & Ends..
Setup..
Measurement..
Ranges..
Autoranging..
Ch1
Auto Ranging
Range1: Yes
Range2: Yes
Range3: Yes
Hysteresis: 10 %
Switchover Levels..
Ch1
Starts & Ends
Range1 Start: 0.000 ppm
Range1 End: 500.000 ppm
Range2 Start: 0.000 ppm
Range2 End: 1000.000 ppm
Range3 Start: 0.000 ppm
Range3 End: 5000.000 ppm
Range4 Start: 0.000 ppm
Range4 End: 10000.000 ppm
