Software Menus
Ch1
Linearization
Linearizer: Off
LinearMethod: Splines
Calculate!
Setpoints (X)..
Actuals (Y)..
Linearizer Min 20.000 ppm
Linearizer Max 110.000 ppm
Status
Normal
6.2.3.3.3 Setup Linearization
6.2.3 Setup Menu
Specify the linearization methode to be
used.
Available options: Splines, Polynom.
Switch On or Off the linearizer.
First enter SETPOINTS (X) to enter the new
setpoint values (
6-51 ).
When done, enter ACTUALS (Y) to enter the
corresponding actuals ( 6-52 ).
Select this line to let the analyzer calculate
the new linearization curve.
The linearization status.
Possible values: Normal, Underow, Over-
ow, Undened
Setup..
Measurement..
Linearization..
If the system is set up accordingly, the access
code for level 3 must be entered to gain ac-
cess to this menu.
