Emerson Process Management GmbH & Co. OHG6-68
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
Digital Outputs (X1)
Output1 Node: System
Output1 Signal: Off
Output2 Node: Ch1
Output2 Signal: Off
Output3 Node: Ch2
Output3 Signal: Off
Output4 Node: Ch3
Output4 Signal:
Off
6.2.3.4.2 Setup Digital Outputs
6.2.3 Setup Menu
This rst menu page enables to congure digi-
tal outputs 1 ... 4, which are the basic outputs,
available with every X-STREAM Enhanced
analyzer ('X1' in the menu title refers to the
instrument´s I/O connector X1).
For each output 1 .. 4 specify within the
"Node" line the signal source.
Available options: System, Ch1…Ch5 (de-
pending on the number of channels installed).
If any one of Ch1…Ch5 is selected, only
signals, valid for the selected channel are
considered.
If System is selected, analyzer specic si-
gnals are selectable.
Once the "Node" is specied, for each output
1…4 select within the "Signal" line, what to
output. Depending on the node, the list of
available signals varies; next page.
Setup..
In-/Outputs..
Digital Outputs..
