Emerson X-STREAM XE User Manual

Emerson Process Management GmbH & Co. OHG 6-67
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus

Cut Mode: Standard
Low Cut: 3.80 mA
High Cut: 20.50 mA
6.2.3 Setup Menu
Note!
This second menu page appears only, if "Fail-
Mode" is set to other than Track! It enables
to specify the output´s behaviour in case the
measured value exceeds the range
(
Tab. 6-2 at page 6-65)
.
"Low Cut" is output if the measured value
is below the lower range limit, "High Cut" is
output if it exceeds the upper range limit.
"Cut Mode" species if Standard values or
Congurable values are used for output:
If "Cut Mode" is set to Standard, these lines
show the standard settings. For "Low Cut"
they depend on the setting of "OutRange":
OutRange 0-20 mA 4-20 mA
Low Cut -0.20 mA 3.80 mA
High Cut 20.50 mA
If "Cut Mode" is set to Cong, use these
lines to adjust the related output signals. The
accepted values for "Low Cut" again depend
on the setting of "OutRange":
OutRange 0-20 mA 4-20 mA
Low Cut -1.80…-0.01 mA 2.20…3.99 mA
High Cut 20.01…21.50 mA
